HIMA HIMatrix F35 Safety-Related Controller: Compact, Reliable, and Powerful

The HIMA HIMatrix F35 is a compact, safety-related controller designed to meet the most demanding automation needs. With its robust performance and high flexibility, the F35 controller provides essential features for critical applications where safety is paramount. This article explores the specifications, features, and advantages of the HIMatrix F35, shedding light on why it’s an ideal choice for industrial and safety-related control systems.

Safety-Related Digital Inputs and Outputs
The HIMA HIMatrix F35 comes equipped with 24 safety-related digital inputs and 8 safety-related digital outputs, ensuring robust safety functions. These digital inputs and outputs are crucial for monitoring and controlling safety-critical processes. Each input and output has an individual LED indicator to clearly signal its state (HIGH or LOW), making it easy to monitor system performance in real-time.

Digital Inputs: The controller’s 24 digital inputs provide reliable detection of various signals. Each input has an LED indicator that signals whether the input is HIGH or LOW, allowing for quick diagnostics and easy troubleshooting.
Digital Outputs: The 8 digital outputs are designed to handle varying load requirements, with outputs 1-3 and 5-7 able to handle up to 0.5 A at maximum ambient temperature. Outputs 4 and 8 can support a higher load of 1 A or even 2 A, depending on the environmental conditions.

These safety-related outputs and inputs are critical for ensuring that processes run smoothly and safely, minimizing the risk of system failures.

Flexible Temperature Range for Diverse Applications
The HIMA HIMatrix F35 is designed to operate effectively in a wide range of temperatures, making it suitable for use in diverse environments. The controller operates within an ambient temperature range of 0°C to +60°C and can withstand storage temperatures from -40°C to +85°C.
Load Handling: At ambient temperatures up to 50°C, the controller’s digital outputs can handle varying current loads of up to 1 A or 2 A, depending on the specific output. For environments ranging from 60°C to 70°C, all outputs remain operational with a maximum load of 0.5 A, ensuring reliability even in more extreme conditions.

Buffering for Date/Time: The controller uses a gold capacitor for maintaining time and date functions, ensuring that time-sensitive processes continue without disruption.

This adaptability to different temperature conditions allows the HIMatrix F35 to be deployed in a variety of industries and environments, from standard factory settings to harsher, more challenging conditions.

Versatile Communication Interfaces
The HIMA HIMatrix F35 is equipped with multiple communication options to ensure seamless integration into any industrial automation network.
Ethernet Interfaces: Four RJ-45 Ethernet interfaces (10BASE-T/100BASE-Tx) with an integrated switch provide fast, reliable communication between the controller and connected devices.
Fieldbus Interfaces: The controller includes three 9-pin D-sub connectors for fieldbus communication. This includes two interfaces (FB1 and FB2) with pluggable fieldbus submodules and one RS485 interface (FB3) supporting Modbus communication, either in master or slave mode.
These versatile interfaces allow the HIMatrix F35 to communicate effectively with various network types, making it easy to integrate into existing infrastructure.

Compact and Robust Design
In addition to its powerful functionality, the HIMA HIMatrix F35 controller is designed with a compact and durable metal housing, making it suitable for both space-constrained and industrial environments. The controller has the following dimensions:
Width: 257 mm
Height: 114 mm
Depth: 97 mm
With a weight of approximately 1.2 kg, the F35 controller is lightweight yet robust enough to handle demanding industrial conditions. Its IP20 protection rating ensures reliable operation, even in environments with moderate dust exposure.

Reliable Power Supply and Operation
The HIMA HIMatrix F35 operates with a 24 VDC power supply, offering a current input maximum of 9 A when the system is under full load. In idle mode, the controller consumes only 0.5 A, ensuring energy efficiency.

Operating Voltage: The controller supports a wide voltage range of -15% to +20% from the rated voltage, providing flexibility in various power supply scenarios.
Fuse Protection: The controller comes with an external 10 A time-lag (T) fuse, adding an extra layer of protection against power surges.
This combination of energy efficiency, flexible voltage handling, and reliable fuse protection ensures that the HIMatrix F35 performs optimally in a variety of operational conditions.

Conclusion
The HIMA HIMatrix F35 Safety-Related Controller is a powerful, compact solution for safety-critical automation tasks. With its extensive range of digital inputs and outputs, robust temperature handling, versatile communication interfaces, and compact design, it is ideal for industries requiring high safety standards. Whether deployed in harsh environments or integrated into complex automation systems, the HIMatrix F35 provides the reliability and safety required to keep operations running smoothly and securely.

If you’re looking for a safety-related controller that combines performance with flexibility, the HIMA HIMatrix F35 is an excellent choice.
